One, Two, Four, or 6 Place System with MH3 or MH4 Flowmeter(s), XCP or FPR Regulator, AL-415 (14.7 cu. ft.) Aluminum Cylinder and Full-Pack
Duration Table (Single Place) For multiple place systems, divide the duration numbers by the number of stations. | ||||||||||||||||
Cylinder | Pressure | Volume | Diameter Max. | Length Max. | Weight Empty | MH4 | MH3 or MH4 | |||||||||
|
| Duration in Hours | Duration in Hours | |||||||||||||
bar | PSI | liters | cu. ft. | cm | inch | cm | inch | Kg | lb | 10K ft | 15K ft | 18K ft | 10K ft | 15K ft | 18K ft | |
AL-415 | 124 | 1800 | 371 | 13.1 | 11.11 | 4.375 | 47.37 | 18.65 | 2.83 | 6.25 | 5.2 | 3.6 | 3.0 | 15.4 | 8.5 | 6.5 |
AL-415 | 139 | 2015 | 415 | 14.7 | 11.11 | 4.375 | 47.37 | 18.65 | 2.83 | 6.25 | 5.8 | 4.0 | 3.4 | 17.2 | 9.5 | 7.2 |
- AL-415 Aluminum Cylinder
- XCP-1P (1 Place) or FPR (4 Place) regulator (CGA-540 type)
- MH3 or MH4 Flowmeter
- Holster Pack for Cylinder
Included:
Not Included:
- Oxygen - The oxygen tank is empty.
To add extra flow stations to any of the 2-place O2D2-2G systems below, add $100 for the FPR 4-place regulator upgrade.
See our Full-Pack cylinder harness & carry-caddy for these cylinders. Also see CMK cylinder hold-down kits.
Also, the optional ALPS FaceMask with or without microphone is the perfect addition to any EDS system.
MH-00XCP-0060-xx
- Brand: Mountain High
- Product Code: XCP-415-xP-MHx-F
- Availability: In Stock
-
$659.00
