Radio- Panel Mount




Links
Becker  Walter Dittel |  Flightline  Trig


Related Pages
Headset Comparison
Microphones
Handheld Radio Comparison
Speakers
Antennas
Aviation Radio Comparison Table







Price for Radio
$1295
$1995
$1530
Price for complete system including:
boom microphone, wiring harness, speaker/wiring junction box, push-to-talk switch
(Antenna not included)
$1891 with
Peiker TM170-23in gooseneck microphone,
DIN-5m-240 connector (for connection to Dittel speaker box) and Goddard: Cable-Becker-AR6201-DittelSpkr-3 wiring harness
$2565 with
Dittel
gooseneck microphone

$2520 with Peiker TM170-23in gooseneck microphone and
DIN-5m-240

$2035 with
Country of Manufacture
Germany
Germany
Edinburgh, Scotland
TSO
Yes
Yes
Yes
Transmit Power Output (carrier)
6 W
5 W
6 W
Transmit Power Output (PEP)

18 W
6 W
Channels
2280
760
2280
Channel Spacing
8.33 kHz
25 kHz
8.33 kHz
"Dual Monitor"
(monitor standby frequency if nothing is being received on main frequency)
Yes
No
Yes
Built-in Intercom
Yes
Yes
Yes
Receive VOR Channels
No
No

Minimum Voltage
9 VDC
9 VDC
8 VDC
(2.5 W output at 9V,
shutdown at 8V)
Current Draw on Standby
85 mA
50 mA
200 mA (receive)
Memory Channels
?
20
9
Speaker (standard)
4 Ohm, 6 Watt
4 Ohm, 30 Watt
4 or 8 Ohm, 4 or more Watt
Microphone Type
Dynamic
(DittelPeiker
Dynamic
(DittelPeiker
Electret
(like aviation headsets)
Alpha Memory Description
YesNo
No
Instrument panel hole size required
57 mm
or
57 x 42.5 mm
57 mm
or
57 x 42.5 mm
57 mm
or
57 x 42.5 mm
Length (behind panel, not including connectors)
168.4 mm (6.631 in)
173 mm (6.81 inches)
35.49 mm (1.40 in)
2nd Seat Repeater Available
Yes
No
No
Antenna Connector
BNC
BNC
TNC
Stuck Microphone Timer

No
Yes
Unique Features
Extremely reliable radio with extremely low current drain. Large text display for easy in-flight reading. Extremely clear sound from standard speaker.
Extremely reliable radio with extremely low current drain. Large text display for easy in-flight reading. Extremely clear sound from standard speaker.
Extremely reliable radio with extremely low current drain. Large text display for easy in-flight reading. Extremely clear sound from standard speaker.









Becker-AR6201

Becker-AR6201

Becker AR6201-022 Compact VHF/AM Transceiver (Panel mounted aviation radio) with 8.33 kHz chann..

$1,395.00

Dittel FSG 2T - Avionics Transceiver

Dittel FSG 2T - Avionics Transceiver

FSG 2T - Avionics Transceiver5 Watt, 760 Channel, 25 kHz channel spacing, 20 channel memory, mounts ..

$2,195.00

Trig-TY91

Trig-TY91

Trig TY91 Panel Mount Aviation RadioThe new TY91 radio is a very interesting product. It looks great..

$1,675.00

Showing 1 to 3 of 3 (1 Pages)
